Blu2Light Light Management

The Future of Light Management

Smart, open and based on Bluetooth®

Existing light points are used to transmit information to consumers in various languages, be it whilst doing the shopping, waiting for a bus or visiting a museum.

  • Completely open communication protocol
  • Blu2Light mesh systems no longer require centralised control.
  • The Blu2Light system luminaire is a neutral platform that permits integration of all known systems such as DALI, DMX, 1–10 V and in addition enables new variants such as Bluetooth® wireless technology to be included directly within the control gear or on the LED's PCB.
  • Blu2Light products are directly integrated into the luminaire.
  • The intelligence of the classic DALI light controller is transferred to a sensor that detects daylight and motion at the same time.
  • Super simple and user-friendly configuration and operation is enabled by an app on a smartphone or tablet.
  • Further functions are available via cloud services.

LED drivers with integrated DALI power supply

PrimeLine NFC L-R1 DALI2 B2L-ready

Click here for the products

Blu2Light is the first completely open Bluetooth® wireless technology system with mesh functionality for the professional lighting market, which, in addition to a variety of functions for lighting control, offers the luminaire manufacturer added IoT benefits with maximum system security.

Here is an overview of the functions of the product series

Innovative DALI controller with Bluetooth® wireless technology


  • Very small casing for easy integration into a luminaire
  • Direct supply via DALI bus, no mains voltage connection necessary
  • Integrated Bluetooth mesh radio module
  • Up to 64 DALI devices addressable


Click here to go to the product

DALI controller with Bluetooth® wireless technology and daylight and motion detection


  • Combined light and motion detection for a mounting height of up to 4 m
  • Direct supply via DALI bus, no mains voltage connection necessary
  • Integrated Bluetooth mesh radio module
  • Up to 64 DALI devices addressable
  • Suitable for integration in ceilings or luminaires


Click here to go to the product

DALI controller with Bluetooth® wireless technology and daylight and motion detection – High-bay edition


  • Combined light and motion detection for a mounting height of up to 12 m
  • Direct supply via DALI bus, no mains voltage connection necessary
  • Integrated Bluetooth mesh radio module
  • Up to 64 DALI devices addressable
  • Suitable for integration in ceilings or luminaires


Click here to go to the product

Innovative multifunctional Bluetooth® sensor for monitoring indoor climate data


  • Combined light and motion detection
  • Self-calibrating CO2 measurement
  • Measurement of temperature and humidity
  • Installation in standard flush-mounted boxes


Click here to go to the product

Here is an overview of the functions of the product series

Wireless double rocker switch push-button with own power supply


  • Manual control via push-button
  • Integrated Bluetooth radio module
  • Maintenance-free thanks to battery-free EnOcean technology
  • Flat frame height


Click here to go to the product

Power-supplied flush-mounted module for standard push-buttons (two inputs)


  • Makes standard push-buttons to Bluetooth push-buttons
  • Integrated Bluetooth radio module
  • Maintenance-free thanks to battery-free or mains supply
  • Installation in standard flush-mounted boxes


Click here to go to the product

The power supplies can be used for existing DALI applications to make them Blu2Light-capable.

Here is an overview of the functions of the product series

The DALI Power Supply serves as a power supply for existing DALI applications in order to make them Blu2Light-capable.



  • Up to 15 DALI devices connectable
  • Up to 5 power supplies parallel connectable
  • Compact casing for luminaire integration
  • Integrated reversible short circuit, overload and over temperature protection


Click here to go to the product



The DALI Power Supply 40 serves as a power supply for existing DALI applications in order to make them Blu2Light-capable.


  • Up to 40 DALI devices connectable
  • Wide input voltage range of 110–240 V AC, 50–60 Hz
  • Compact casing for luminaire integration
  • Integrated reversible short circuit and overload protection


Click here to go to the product

For larger applications, the Extender 64 also serves as a power supply for existing DALI applications to make them Blu2Light-enabled.



  • Up to 64 DALI devices connectable
  • Allows extension of the DALI line by up to 300 m
  • Primary side DALI current consumption: 2 mA
  • Casing with cord grip for independent operation


Click here to go to the product

With the two apps LiNA Connect and LiNA Touch, you can configure and operate your Blu2Light system.

Here is an overview of the functions of the product series

The commissioning app for iOS

You only need the one app for the complete system setup.
LiNA Connect also allows you to create LiNA Touch user profiles that are used in the LiNA Touch app.

Compatible iPads:
iPad mini
iPad 9.7" (9.7")
iPad Pro 10.5 / 11" / 12.9" / 12.9""

Operating Manual LiNA Connect (PDF)

The operator app for the Blu2Light system

With LiNA Touch, you can easily operate any Blu2Light system with your smartphone or tablet (iOS and Android).



Operating Manual LiNA Touch (PDF)
